Brand: NITGEN
Product Code: SW101-M2R
Availability: In Stock
Product Overview:
> 32 bit CPU,8MB RAM/8MB flash memory.
> LCD screen, finger print sensor,2000 template capacity.
> 1000 finger print capacity.
> 20000log capacity.
> TCP/IP/RS485/Wiegand communication.
> 20~60℃ operating temperature.
> 77x178x50mm dimension.
Product Specification:
|
CPU |
32 bit / 200MHz (Marvell) |
|
|
Memory |
8MB DRAM / 8MB Flash |
|
|
Display |
122×32 Graphic LCD (Black&White) |
|
|
FP Sensor |
Type |
Optical |
|
Resolution |
500 DPI |
|
|
Authentication Mode |
Fingerprint, Password, RF Card |
|
|
1:1 verification Time |
< 1 sec. |
|
|
1:N Identification Time |
< 2 sec.(2,000 templates) |
|
|
Template capacity |
2,000 templates(2templates/1finger, 1,000 user) |
|
|
Log capacity |
20,000 logs |
|
|
Communication |
TCP/IP, RS485(TBD), Wiegand In/Out(26/34 bit) |
|
|
Output Relay |
Deadbolt, EM Lock, Door Strike, Automatic Door |
|
|
Operating Temperature |
-20~60 ℃ |
|
|
Operation Humidity |
< RH 90 % |
|
|
Certification |
KC, CE, FCC |
|
|
Size |
77(W) x 178(L) x 50(D) mm |
|
