Brand: TVT
Product Code: TD-7420AS2L(D/IR1)
Availability: In Stock
Product Overview:
· 1080P real-time image, high resolution, true color
· AHD / TVI / CVI /CVBS standard and lossless video output
· Up to 1000 TVL resolution
· CMOS progressive scan, perfectly capture the moving object
· Support OSD menu
· High speed, long distance and real time transmission
· Auto color to B / W at low illumination
· Support ICR switch, true day / night, digital WDR
· Support noise reduction function
· 10 ~ 20m IR night view distance
· IP66 ingress protection
· Support COC
Product Specification:
Model
TD-7420AS2L
Camera
Image Sensor
1 / 3.2"CMOS
Resolution
2MP
Image Size
1920 x 1080
Video Output
AHD / TVI /CVI/CVBS
Image System
PAL / NTSC
Electronic Shutter
Auto; 1 / 50s ~ 1 / 100000s ( PAL );
1 / 60s ~ 1 / 100000s ( NTSC )
IR Distance
10 ~20 m
Frame Rate
30fps(60Hz); 25fps (50Hz)
Min. Illumination
0 lux (IR ON)
Lens
3.6 mm
Lens Mount
M12
S / N Ratio
≥52dB ( AGC OFF )
Ingress Protection
IP 66
Functions
Function Control
OSD ( COC Control )
Day & Night
ICR
Digital WDR
Yes
Digital NR
Yes
AGC
Yes
Auto White Balance
Yes
BLC
Yes
FLC
Yes
Defog
No
HLC
No
Sharpness
Yes
Mirror
Yes
Smart IR
Yes
Image Setting
Yes
Defect Correction
Auto
Language
Chinese and English
Angle Adjustment
Pan: 0°~360°; Tilt: 0°~90°; Rotation: 0°~360°
Others
Power Supply
DC12V ( ± 10% )
Power Consumption
IR OFF : < 1W; IR ON : < 3W
Working Environment
- 30 °C ~ 50 °C, 10 % ~ 90 %（relative humidity）
Dimensions ( mm )
Ф 65 x 144
Weight ( net )
Approx. 0.15KG
